技術參數
產品型號
|
螺紋規格
|
適用電纜
|
H(mm)
|
螺紋外徑
|
螺紋長度
|
扳手直徑 (mm)
|
數量/袋
|
ZD-PG7-R
|
PG7
|
3~6.5
|
54
|
12.5
|
9
|
18/16
|
100
|
ZD-PG7-R
|
PG7
|
2~5
|
54
|
12.5
|
9
|
18/16
|
100
|
ZD-PG9-R
|
PG9
|
4~8
|
63
|
15.2
|
9
|
22/19
|
100
|
ZD-PG9-R
|
PG9
|
2~6
|
63
|
15.2
|
9
|
22/19
|
100
|
ZD-PG11-R
|
PG11
|
5~10
|
78
|
18.6
|
9
|
24/22
|
100
|
ZD-PG11-R
|
PG11
|
3~7
|
78
|
18.6
|
9
|
24/22
|
100
|
ZD-PG13.5-R
|
PG13.5
|
6~11
|
90
|
20.4
|
9
|
27/24
|
100
|
ZD-PG13.5-R
|
PG13.5
|
5~9
|
90
|
20.4
|
9
|
27/24
|
100
|
ZD-PG16-R
|
PG16
|
10~14
|
100
|
22.5
|
10
|
30/27
|
100
|
ZD-PG16-R
|
PG16
|
7~12
|
100
|
22.5
|
10
|
30/27
|
100
|
ZD-PG21-R
|
PG21
|
13~18
|
112
|
28.3
|
12
|
35/33
|
100
|
ZD-PG21-R
|
PG21
|
9~16
|
112
|
28.3
|
12
|
35/33
|
100
|
|
